Features:
– Comparable to a 1,800W PAR or 2,500W HMI Fresnel
– Provides powerful, flicker-free and natural-looking light
– Dimmable in 0.1% increments
– Integrated display for brightness, effects, radio/DMX channel, menu functions and more.
– Supports wireless control via Nanlink APP, DMX/RDM, 2.5 GHz Bluetooth and Lumenradio TimoTwo, as well as wired control or control directly on the luminaire
– Simple and intuitive operation with versatile, controllable performance
– Integrated effects such as flash, pulse, storm, TV, paparazzi, defective bulb and more
– Integrated NL mount for quick change of different optics
– Includes removable reflector
– Includes swivelling mounting bracket with quick-release function and 16 mm (5/8″) spigot
– Power supply via included power adapter
– Robust construction and protection against dust and splash water (IP54)

Technical data:
– Light source: 1x COB LED, 1200W
– Colour temperature: daylight/neutral white (5600K)
– Dimmer: 0%-100%, in 0.1% increments
– TLCI: 97
– CRI: 96
– Operating voltage: 48V, 25A max.
– Power supply: 100-240V, 50/60 Hz
– Cooling: Active cooling
– Mounting option: NL bracket
– Certificates: CE, UKCA, PSE, KCC, ROHS, KUCAS
– Protection rating: IP54

Light intensity:
– Light: 3 m: 5532 lx, 5 m: 2373 lx, 7 m: 1266 lx, 10 m: 679 lx
– With reflector: 3 m: 18,460 lx, 5 m: 6,583 lx, 7 m: 3,671 lx, 10 m: 2,021 lx
– With 11° Fresnel: 3m: 65280 lx, 5m: 22080 lx, 7m: 11765 lx, 10m: 6308 lx
– With 30° Fresnel: 3m: 25560 lx, 5m: 10640 lx, 7m: 5674 lx, 10m: 3043 lx
– With 45° Fresnel: 3m: 15170 lx, 5m: 5718 lx, 7m: 3065 lx, 10m: 1644 lx

General:
– Dimensions (Evoke without yoke): 330 x 241 x 210 mm
– Dimensions (Evoke with yoke): 503 x 370 x 210 mm
– Dimensions (power supply): 376.5 x 181 x 246 mm
– Weight (light): 6.94 kg
– Weight (yoke): 1.84 kg
– Weight (power supply): 10.5 kg

Data Focusable Fresnel attachment for NANLUX Evoke 1200

Features:
– Continuously adjustable light output angle from 11° to 45°
– Fresnel lens for focusing the light and achieving higher illuminance
– Rotatable and removable attachment with four light flaps for targeted light control
– Middle flaps can be opened separately
– Easy attachment to the spotlight via NL mount
– Compatible with NANLUX Evoke 1200

Flight case for NANLUX Evoke 1200

Features:
– Provides space for one NANLUX Evoke 1200
– Robust construction
– Custom fit
– Maximum protection thanks to padded interior
– Integrated compartments
– Includes wheels for easy transport

Nanlux Evoke 1200B LED Set

includes:

• incl.
• 1× Evoke 1200B headlight
• 1× Fresnel lens (FL-35YK)
• 1× Yoke
• 1× Reflector (RF-NLM-45)
• 1× power supply unit
• 1× DC connection cable 7.5m
• 1× Power cable 6m
• 1× Evoke Quick Release clamp (AS-CP-QR-EV)
• 1× USB stick
• 1× Remote control (WS-RC-C2)
• 1× Flight case (CC-EV1200-FL-YK-FT)
